High-Speed InGaAs SWIR Line-Scan Camera
LiSa SWIR Linescan Camera
LiSa is a high-speed InGaAs SWIR line-scan camera for continuous machine-vision inspection of moving materials. Its 2048 × 1 sensor, greater than 110 kHz full-resolution line rate, external triggering and Camera Link interface support semiconductor, photovoltaic, food, recycling, web and process-control applications.
LiSa Linescan SWIR Camera
Product Overview
Continuous SWIR Imaging at Production-Line Speeds
Unlike an area-scan camera, LiSa records one line of SWIR pixels at a time. As a conveyor, web, wafer or scanning stage moves the target, successive lines are assembled into a continuous 2-D image. This architecture is ideal for materials already moving through an industrial process.
The InGaAs detector operates across the standard SWIR region, where silicon, moisture, polymers, coatings and organic materials can show contrast that is weak or invisible to conventional visible cameras.
Explore SWIR Linescan Imaging →
LiSa at a Glance
- 2048 × 1 InGaAs sensor
- 0.9–1.7 µm response
- >80% QE
- >110 kHz full-resolution line rate
- 1 µs minimum integration time
- ROI for higher rates
- External / software / Camera Link triggering
- GenICam / GenCP
- C-mount
Applications
Where LiSa Adds Value
Semiconductor & Silicon
Inspect wafers and substrates for cracks, edge defects, inclusions and selected through-silicon features.
Semiconductor inspection →Photovoltaic Inspection
Inspect silicon solar cells for cracks, process defects and non-uniformities during manufacturing.
Linescan application guide →Food & Agriculture
Use SWIR contrast associated with moisture, drying, foreign material and composition on moving conveyors.
Machine vision →Plastics & Recycling
Use wavelength-dependent material contrast for high-throughput sorting and recycling.
Material identification →Moisture & Coatings
Inspect moisture variation, coatings, adhesives and sealants continuously across moving materials.
Web & Roll Inspection
Inspect paper, film, textiles, foil, battery materials and other continuous webs across their full width.
Why Choose LiSa?
Designed for High-Speed SWIR Machine Vision
High Line Rate
Full-resolution operation above 110 kHz supports fast conveyors, webs and scanning stages. Reduced ROI can increase acquisition rate further.
Flexible Triggering
Internal, external LVTTL, software and Camera Link triggering support synchronization with encoders, PLCs and illumination.
Industrial Integration
Camera Link Base output, GenICam / GenCP control and selectable pixel formats support machine-vision integration.
Technical Data
LiSa Technical Specifications
| Specification | LiSa |
|---|---|
| Sensor / material | NSC2301 / InGaAs |
| Resolution | 2048 × 1 |
| Pixel size | 8 × 14 µm | 8 × 200 µm |
| Spectral response | 0.9 to 1.7 µm |
| Response / modes | Linear, Low/Medium/High Gain; ITR, IWR, ROI |
| QE | >80% |
| Full-resolution line rate | >110 kHz |
| Minimum integration | 1 µs; camera register or trigger-width control |
| Trigger | Internal / External (LVTTL), Software, Camera Link |
| ROI | User-selectable in 8-pixel steps; reduced ROI increases maximum rate |
| Read-out noise | High gain (CDS): <90 e−; Medium: <370 e−; Low: <2200 e− |
| Dynamic range | High: 55 dB typical; Medium: 62 dB; Low: 66 dB |
| Control | GenICam / GenCP |
| Output | Camera Link Base; 8 / 10 / 12 / 14-bit formats |
| Camera power | <4 W |
| TEC cooling | Off; Low <1 W; Medium <2 W; High <5 W |
| Operating temperature | −40 to +71 °C |
| Dimensions / weight | 45.4 × 75 × 58 mm / 280 g |
| Lens mount | C-Mount |
| Software | NITGenicamControlTool — Windows, camera control only |
System Design
Define the Complete Inspection Requirement
Inspection Width
Specify field of view across the target.
Smallest Feature
Define the smallest defect that must be detected.
Line Speed
Provide conveyor speed and desired sampling.
Wavelength & Lighting
Select reflective, transmitted, backlight or wavelength-specific illumination.
Mechanical Geometry
Confirm working distance, focal length and available space.
Interface & Software
Define frame grabber, trigger, GenICam, processing and PLC requirements.
Video
See SWIR Linescan Imaging in Action
Application Engineering & Pricing
Need Help Configuring a LiSa Linescan System?
Send the material, inspection width, smallest defect, conveyor speed, working distance, wavelength requirements, interface and software environment. Pembroke Instruments can help match the camera, lens, illumination, triggering and processing approach to the application.
